SKU: R2-2030Z8SK3/45L AM.CO.ZA® EasyRoute™ Heavy Duty 380V Raised Z-800mm 2050×3050mm PVC Clampable Vacuum CNC Router with Pneumatic Automatic Tool Changer of Three 4.5kW High-Torque Water-Cooled Spindles Triple Heads and Servo Motors
AM.CO.ZA® EasyRoute™ Heavy Duty 380V Raised Z-800mm 2050×3050mm PVC Clampable Vacuum CNC Router with Pneumatic Automatic Tool Changer of Three 4.5kW High-Torque Water-Cooled Spindles Triple Heads and Servo Motors
Product SKU:
R2-2030Z8SK3/45L
Product Name:
AM.CO.ZA® EasyRoute™ Heavy Duty 380V Raised Z-800mm 2050×3050mm PVC Clampable Vacuum CNC Router with Pneumatic Automatic Tool Changer of Three 4.5kW High-Torque Water-Cooled Spindles Triple Heads and Servo Motors
EasyRoute Heavy Duty 380V Raised Z-800mm 2050x3050mm PVC Clampable Vacuum CNC Router, Pneumatic Automatic Tool Changer of Three 4.5kW High-Torque Water-Cooled Spindles Triple Heads & Servo Motors
Free First Time Spindle Bearing Service Suitable Foam Materials Machining 1 Year Limited Warranty Service Plan 3 Months Interval for 2 Years Maintenance Plan for 2 Years Training Course 1 Day Barcode Database & Service History
The saturation, shapes or characteristics of the machinery may vary from that in the pictures as all the images are for show purposes only. While preserve all major attributes and description we retain the liberty to modify, abolish or upgrade minor attributes. You can request a index of features in advance if desired.
All the pictures are for demonstration purposes only, therefore the machines' colours, shape or features may differ from that in the picture. We reserve the rights to change, remove or improve minor features while retaining the major features and specs. You are welcome to request a latest list of features beforehand.
(Compartment) EasyRoute™ Heavy Duty Servo 380V Control Box, with 7.5kW Inverter, 4 Servo Motor Drivers and Other Electric Essentials
R2-GANTRY/S2030/Z8
(Compartment) EasyRoute™ Heavy Duty Servo 800mm Z-Axis 2050×3050mm Working Area Gantry Structure with Four 1.5kW Servo Motors and Single Water-Cooling Spindle Supporting Structure
AM.CO.ZA® EasyRoute™ Heavy Duty 380V Raised Z-800mm 2050×3050mm PVC Clampable Vacuum CNC Router with Pneumatic Automatic Tool Changer of Three 4.5kW High-Torque Water-Cooled Spindles Triple Heads and Servo Motors Features and Highlights
Water-Cooled Chiller Uses Single Phase 220V Household Power, No AC Power Plug Included
Water-Cooled Chiller Radiating capacity 50W/°C with Energy Saving, Long Working Life Deisng
Water Chiller Maximum Pump Flow Rate 10L/min and Maximum Pump Lift 10 Metres Distance
Chiller Water Tank Capacity 9L, Purified Water Required (Not Supplied), Replace Monthly Suggested
DSP Controller use ARM Cortex-A8 800MHz CPU with 512MB Internal Cache and 512MB Flush Memory for Storage
Heavy Duty Version Much More Accurate and Better Performance on Long Run with Double the Warranty Time
Servo Motors Give Your Much Better Accuracy, Much Faster Speed and Much More Torch. Total 4 Servo Motors Used, Two on Y-Axis
Z-Axis Setter/Presetter Included, Automatic Measure Tool Length and Establish 0 Reference Point
Clampable Vacuum Table Surface Made By PVC with Aluminium Clamping T-Slots Build In
With 125mm Diameter 4.5kW High-Torque Water-Cooled Spindle on 7.5kW Inverter for Maximum 24000RPM with ER25 Collet Size
Working Area 2050×3050×800mm on X/Y/Z, the Area Spindle Can Reach
Achieve 0.01mm Resolution on All Axis
Achieve Under 0.05mm Per Meter Accuracy and Repeatability on All Axis
High-Load, High-Speed Caged Ball Screw Transmission System on Z Axis
Use Industrial 380V 3-Phase Electricity, 5 Pin 32A Plug with 4mm² Cable Required and Not Included
High Precision Rack and Pinion System with Helical Teeth Driving System on X and Y Axis
Accept All Kinds of G-Code File (*.g;*.nc;*.ug;*.demo;*.iso;*.eng;*.cut;*.dxf;*.plt;*.txt) by USB Flush Drive, G-Code File Size Up to 256M
Linear Guide Rail in Twin Parallels Structure and Two Roller Bearing Sliders on Each Rail Guide X/Y/Z Movement
With Rotary Attachment Supporting Interface and can Switch between Rotary Rotating and X-Axis Linear Movement
Rugged Keypad Against Water, Oil, Dust and Collision, Cheap and Easy to Replace If Damaged
Triple Spindle Heads Driven by Compressed Air for Pneumatic Automatic Tool Change of 3 Tools
Maximum 80 Meter Per Minute Moving Speed on X/Y Axis, With Factory Default on 25 Meters/Min
With Standalone AM.CO.ZA® EasyRoute Control System, No Computer Needed, Stable System Suitable for Industrial Usage
Maximum 5 Meter Per Minute Moving Speed on Z Axis, With Factory Default on 3 Meters/Min
Left and Right Spindles Allow to Manually Adjust from Vertical to Horizontal or Any Angle in Between for Side Slotting/Drilling
Free First Spindle Service: The spindle is required to be replaced when replacing/servicing the bearing time by time. This has to be done once a year for normal, general use, but more frequently for heavy usage. Currently, spindle services and bearing replacement procedures are outsourced and may therefore require longer to service. However, during the bearing replacement/spindle service procedure, we will always have preconditioned spindle ready for you while your spindle is serviced. Your first spindle service is free within electronic components warranty period. The spindle is required to be replaced when replacing/servicing the bearing time by time. This has to be done once a year for normal, general use, but more frequently for heavy usage. Currently, spindle services and bearing replacement procedures are outsourced and may therefore require longer to service. However, during the bearing replacement/spindle service procedure, we will always have preconditioned spindle ready for you while your spindle is serviced. Your first spindle service is free within electronic components warranty period.
Suitable Machining Foam Materials: This router has raised a gantry and is only designed and built for machining foam materials, which generally are considered as plastic or rubber formed by trapping pockets of gas. Any material that cannot be sliced by knife or by hand is considered too hard and is NOT allowed to be machined on this CNC router, otherwise your warranty on this machine will become null and void. This router has raised a gantry and is only designed and built for machining foam materials, which generally are considered as plastic or rubber formed by trapping pockets of gas. Any material that cannot be sliced by knife or by hand is considered too hard and is NOT allowed to be machined on this CNC router, otherwise your warranty on this machine will become null and void.
Quality Warranty: For the whole machinery, and each subsystem, we only supply constrained attribute guarantee unless stated differently. Errors by reason of unfit equipment or poor craftsmanship, are covered by the trait guarantee. We cannot be held liable for misuse or common wear and tear of your machine. Aforementioned is therefore not covered by our warranty. Damages can usually be repaired that aren't covered under guarantee, at minimum cost. Upon demand, quotations are promptly accessible.
Some items within your purchase come with different warranty terms and period:
We provide limited product warranty on the parts of the machine, and for such periods, as set out below, as well as the relevant subsystem to such parts. The quality warranty is intended to cover, and is accordingly limited to, defects arising due to faulty materials or poor craftsmanship in relation to production and manufacture of the machine. We shall not be responsible for common wear and tear nor misuse of the machine or relevant parts.
Some items within your purchase come with different warranty terms and period:
Service Plan: The machine(s) you are going to purchase needs a regular service. The covered service plan includes general cleaning, reviewing and positioning, as well as standard decrement restoration at a minimum cost. Your service guarantee will be worthless and void if you do not service your machine in the chosen service or if it is not rectified in the equal of double that period. This is to say that in which case we choose that your machinery is fixed once every 3 months, it is required that you get your machine improved in every 6 month period or your warranty will not be legit. By their very nature the machine(s) require regular servicing and maintenance. We therefore provide a mandatory Service Schedule in respect of each machine, which Service Schedule sets out the intervals in which the machine is to be serviced. Our Service offering, which is undertaken at your cost, includes standard cleaning, checking and calibration, as well as common wear and tear replacement, as may be necessary. Should you fail to adhere to the terms of the machine’s Service Schedule and/or not service your machine within the mandatory service intervals, then the Product Warranty shall automatically lapse and we shall no longer be responsible for the service of the machine(s), unless we otherwise agree to service the machine pre agreed cost, and provided that such ad hoc or sporadic service to the machine shall not be regarded as having revived the Product Warranty insofar as the Product Warranty may have lapsed by virtue of the failure to adhere to the Service Schedule.
Call-out Service & Fee: Every time a service is offered at your place by a technician, it refers to a call-out. Except for when accepted by management or included by each of the above mentioned plans, a call-out fee will be charged. One specialist for 1 day is R 1 499.00 for weekdays, Traveling for Saturdays including R 9 995.00 for resting days or Public Holidays at the point of this quotation.Settlement as well as transport costs to your place, along with the call-out fee, are on your account if necessary. The arrangements for the technician to get picked up including sent back are chosen to be done by you. R 9.95/kilometer is the prevailing percentage multiplied by the driving distance between your premises as well as our premises, should you recommend for us to come to you.Without notice, those fees may change instant by extent, thus beneficially analyze about call out as well as traveling costs beforehand A Call-out refers to any time a technician provides a service at your premises. Unless the call-out is covered by any of the above plans or arranged by the management, a call-out fee will be charged. At the time of this quotation, one technician for one day is R 1 499.00 for weekdays, R 4 995.00 for Saturdays and R 9 995.00 for Sundays or Public Holidays.In addition to the call-out charge, travel costs to your premises as well as accommodation if necessary are on your account. We prefer that you arrange that the technician picked up and sent back. If you would like us to travel to you, the current rate is R 9.95/km multiplied by the driving distance between our branch and your premises. Those charges may change time by time without notice, so kindly enquire about call-out and travel costs beforehand. Barring work to be undertaking under the Product Warranty, any maintenance (whether in accordance with the Service Schedule or otherwise), repair or part replacement (whether hardware or software) will be affected at our earliest availability on a first come first serve booking basis, subject to the availability of parts (given the age of the machine) and provided that you have accepted our quotation for such maintenance, repair or part replacement services.
Maintenance Plan (Check-up Callouts): Our service plan is perfect for you if you simply want our technician to take a look at your appliance for peace of mind, or if you want to know if the machine is fitted to work optically. There is no cost for the specialist we supply. Our technician will be able to provide you with guidance on whether an back-up or further servicing or spares reinstatement is needed or if everything is in order. During sustainment visits no adjustments or excessive labour work will be completed and bookings can be made for this to be carried out at your and our quickest convenience. If at any time you would like to ensure that your machine is set to function optimally, or you simply want our technician to inspect your machine then you are welcome to call us and make a booking for Check-up Callout and one of our technicians will come out to you, at the cost of travel and reduced or waived standard call-out cost. Our technician will be able to advise whether the machine is functioning optimally or whether additional service, repair or part replacements are, or may be, needed. Unfortunately, no repair or intense labour work will be carried within our Check-up Callout, but a booking can be made for such maintenance or repair work to be carried out at our earliest availability.
Training Course: Fundamental and/or extensive training courses are held through our warehouse for all machines we sell. More advanced training can be bought after the principal course has been completed however first basic entry courses is included in your machine investment. We offer basic and/or comprehensive training courses through our training facility for all machines we sell. First basic entry course is included in your machine purchase; more advanced training can be obtained after the basic course has been passed.
Barcode System: All our mainline of machinery's are sold with a unique barcode. You will therefore constantly be able to analyze the machine's assurance info and servicing history on our webpage or while logged off - in any way and at any time. Our machinery's assurance and maintenance are honoured by us using the barcode. This protects your supreme comfort on both the assistance and resell of your machines. All our mainline of machines are sold with a unique barcode. You will therefore always be able to check the machine's warranty information and service history on our website or mobile app - in any way and at any time. We honour our machines' warranty and service by using the barcode. This ensures your maximum convenience on both the maintenance and resell of your machinery.
Latest Model Quoted: The above tender relates to our advanced model, therefore the focus points, specifications and additions are suited thereto. Beneficially analyze from our sales assistant as to the year model quoted. You will be entitled to pocket a 5% allowance on previous models , depending on insignificant completion or minor composition in which case we don't have the recent model obtainable. The quotation above pertains to our newest model, and as such the highlights, specifications, accessories are applicable thereto. Kindly enquire from our sales representative as to the year model quoted. In the event that we do not have the newest model available, you will be entitled to receive up to 5% discount on the older model, dependent on lesser performance or lesser design.
