Free First Time Spindle Bearing Service Suitable Machining Aluminum 1 Year Limited Warranty Service Plan 3 Months Interval for 1 Year Maintenance Plan for 1 Year Training Course 1 Day Barcode Database & Service History
The machines in the photograph's saturation, silhouettes or attributes may diverge from that in the icons as all the illustrations are for illustration purposes only. We retain the entitlement to modify, remove or upgrade minor quality while preserve the utmost qualities and descriptions. You can request a catalog of features in advance if desired.
All the pictures are for demonstration purposes only, therefore the machines' colours, shape or features may differ from that in the picture. We reserve the rights to change, remove or improve minor features while retaining the major features and specs. You are welcome to request a latest list of features beforehand.
AM.CO.ZA® EasyRoute™ 220V Lower 1300×2500mm PVC Clampable Vacuum CNC Router with 3kW Water-Cooled Spindle and Stepper Motors Features and Highlights
Water Chiller Maximum Pump Flow Rate 10L/min and Maximum Pump Lift 10 Metres Distance
Water-Cooled Chiller Uses Single Phase 220V Household Power, No AC Power Plug Included
Water-Cooled Chiller Radiating capacity 50W/°C with Energy Saving, Long Working Life Design
DSP Controller use ARM Cortex-A8 800MHz CPU with 512MB Internal Cache and 512MB Flush Memory for Storage
Our CNC Router Machines are shipped to South Africa in disassembled parts due to their large size and weight, which makes transportation challenging. This process may result in minor defects such as scratches, dents, small cracks, or light rust. However, these defects will not affect the machine's intended function and performance. We will touch up any visible defects when possible, but some minor imperfections may still be present in the final delivered CNC Router Machines;
Clampable Vacuum Table Surface Made By PVC with Aluminium Clamping T-Slots Build In
Total Four Stepper Motors on All Axis, Two Stepper Motors on Y-Axis
Chiller Water Tank Capacity 9L, Purified Water Required (Not Supplied), Replace Monthly Suggested
With 3kW Water-Cool Spindle on 3.2kW Inverter for Maximum 24000RPM with ER20 Collet Size
Achieve Under 0.5mm Per Meter Accuracy and Repeatability on All Axis
Z-Axis Setter/Presetter Included, Automatic Measure Tool Length and Establish 0 Reference Point
Maximum 5 Meter Per Minute Moving Speed on Z Axis, With Factory Default on 3 Meters/Min
Achieve 0.01mm Resolution on All Axis
Use Household 220V Single-Phase Electricity, 3 Pin 16A Plug with 2.5mm² Cable (or minimal 4mm² Cable on 40A breaker if Connect Vacuum Pump & Dust Extractor) Required and Not Included
Working Area 1300×2500×200mm on X/Y/Z, the Area Spindle Can Reach
High Precision Rack and Pinion System with Helical Teeth Driving System on X and Y Axis
Linear Guide Rail in Twin Parallels Structure and Two Roller Bearing Sliders on Each Rail Guide X/Y/Z Movement
Maximum 20 Meter Per Minute Moving Speed on X/Y Axis, With Factory Default on 12 Meters/Min
With Standalone AM.CO.ZA® EasyRoute Control System, No Computer Needed, Stable System Suitable for Industrial Usage
High-Load, High-Speed Caged Ball Screw Transmission System on Z Axis
Accept All Kinds of G-Code File (*.g;*.nc;*.ug;*.demo;*.iso;*.eng;*.cut;*.dxf;*.plt;*.txt) by USB Flush Drive, G-Code File Size Up to 256M
Rugged Keypad Against Water, Oil, Dust and Collision, Cheap and Easy to Replace If Damaged
Free First Spindle Service: The spindle is required to be replaced when replacing/servicing the bearing time by time. This has to be done once a year for normal, general use, but more frequently for heavy usage. Currently, spindle services and bearing replacement procedures are outsourced and may therefore require longer to service. However, during the bearing replacement/spindle service procedure, we will always have preconditioned spindle ready for you while your spindle is serviced. Your first spindle service is free within electronic components warranty period. The spindle is required to be replaced when replacing/servicing the bearing time by time. This has to be done once a year for normal, general use, but more frequently for heavy usage. Currently, spindle services and bearing replacement procedures are outsourced and may therefore require longer to service. However, during the bearing replacement/spindle service procedure, we will always have preconditioned spindle ready for you while your spindle is serviced. Your first spindle service is free within electronic components warranty period.
Suitable Machining Aluminum: This router is designed strong enough to to cut and engrave on solid aluminum plate, copper and other soft metal, including on any other materials softer than soft metal. This machine is not designed to cut and engrave on steel, stainless steel etc. For thin steel plate cutting requirements, written consent from management is required for quality warranty. This router is designed strong enough to to cut and engrave on solid aluminum plate, copper and other soft metal, including on any other materials softer than soft metal. This machine is not designed to cut and engrave on steel, stainless steel etc. For thin steel plate cutting requirements, written consent from management is required for quality warranty.
Quality Warranty: For the whole machinery, including any subsystem, we only provide confined quality guarantee if not stated differently. The characteristic warranty covers defects due to faulty materials or poor craftsmanship Everyday wear and tear or mis-usage of your component is not our liability. Our guarantee will for this reason not cover aforesaid. Often damages can be repaired at minimum cost that aren't covered under guarantee. Upon demand, quotations are promptly accessible.
Some items within your purchase come with different warranty terms and period:
We provide limited product warranty on the parts of the machine, and for such periods, as set out below, as well as the relevant subsystem to such parts. The quality warranty is intended to cover, and is accordingly limited to, defects arising due to faulty materials or poor craftsmanship in relation to production and manufacture of the machine. We shall not be responsible for common wear and tear nor misuse of the machine or relevant parts.
Some items within your purchase come with different warranty terms and period:
Service Plan: Regular service is due by the machinery you are going to buy. Standard decrement replacement at a minimal cost, reviewing and adjustment as well as common cleaning are covered within the service plan. It is crucial that your machine(s) is fixed within the equal of twice that period, if you do not service your machinery within the preferred service period, elseways your service warranty will be null and ineffective. Meaning that within which case we recommend that your machine is rectified once every three months, it is necessary that you get your machinery improved within every 6 month period or your guarantee will not be valid. By their very nature the machine(s) require regular servicing and maintenance. We therefore provide a mandatory Service Schedule in respect of each machine, which Service Schedule sets out the intervals in which the machine is to be serviced. Our Service offering, which is undertaken at your cost, includes standard cleaning, checking and calibration, as well as common wear and tear replacement, as may be necessary. Should you fail to adhere to the terms of the machine’s Service Schedule and/or not service your machine within the mandatory service intervals, then the Product Warranty shall automatically lapse and we shall no longer be responsible for the service of the machine(s), unless we otherwise agree to service the machine pre agreed cost, and provided that such ad hoc or sporadic service to the machine shall not be regarded as having revived the Product Warranty insofar as the Product Warranty may have lapsed by virtue of the failure to adhere to the Service Schedule.
Call-out Service & Fee: Whenever a specialist supplies a service at your place, it refers to a call-out. Unless the call-out is enclosed by any of the above mentioned plans or confirmed by the the company, a call-out cost will be requested. One technician for 1 day is R 1 499.00 for workdays, Traveling for Saturdays and R 9 995.00 for Sundays or Public Holidays at the extent of this quotation.Along with the call-out charge, transport costs to your place including accommodation if crucial, are on your account. The arrangements for the technician to get picked up as well as sent back are recommend to be carried out by you. R 9.95/km is the current percentage multiplied by the traveling distance between your property as well as our workshop, should you desire for us to come to you.Kindly enquire about call out as well as traveling costs in advance as those fees may change time by extent without notice. A Call-out refers to any time a technician provides a service at your premises. Unless the call-out is covered by any of the above plans or arranged by the management, a call-out fee will be charged. At the time of this quotation, one technician for one day is R 1 499.00 for weekdays, R 4 995.00 for Saturdays and R 9 995.00 for Sundays or Public Holidays.In addition to the call-out charge, travel costs to your premises as well as accommodation if necessary are on your account. We prefer that you arrange that the technician picked up and sent back. If you would like us to travel to you, the current rate is R 9.95/km multiplied by the driving distance between our branch and your premises. Those charges may change time by time without notice, so kindly enquire about call-out and travel costs beforehand. Barring work to be undertaking under the Product Warranty, any maintenance (whether in accordance with the Service Schedule or otherwise), repair or part replacement (whether hardware or software) will be affected at our earliest availability on a first come first serve booking basis, subject to the availability of parts (given the age of the machine) and provided that you have accepted our quotation for such maintenance, repair or part replacement services.
Maintenance Plan (Check-up Callouts): If you would choose to know if the machine is adjusted to work optically, or you simply want our technician to take a look at your machinery for your satisfaction, our assistance plan is here for you. No fees will be assigned for the technician we provide. Our experts will be able to advise if everything is in order or whether an alternative or other maintenance or spares replacement is needed. During preservation visits no reconstruction or intense labour operate will be done and bookings should made for this to be carried out at your and our earliest convenience. If at any time you would like to ensure that your machine is set to function optimally, or you simply want our technician to inspect your machine then you are welcome to call us and make a booking for Check-up Callout and one of our technicians will come out to you, at the cost of travel and reduced or waived standard call-out cost. Our technician will be able to advise whether the machine is functioning optimally or whether additional service, repair or part replacements are, or may be, needed. Unfortunately, no repair or intense labour work will be carried within our Check-up Callout, but a booking can be made for such maintenance or repair work to be carried out at our earliest availability.
Training Course: Our warehouse offers basic and/or full training courses for all machinery we sell. When obtaining your machinery, first primary entry courses is included in your investment, however more advanced training can be purchased after the primary course has been accomplished. We offer basic and/or comprehensive training courses through our training facility for all machines we sell. First basic entry course is included in your machine purchase; more advanced training can be obtained after the basic course has been passed.
Barcode System: All our mainline of machinery's are sold with a individual barcode. For this reason your machines assurance report and maintenance history will regularly be able to be reviewed in any way and at any instant on our webpage or offline. We value our machinery's warranty and service by using the barcode. This insures your maximal comfort on both the assistance and resell of your machines. All our mainline of machines are sold with a unique barcode. You will therefore always be able to check the machine's warranty information and service history on our website or mobile app - in any way and at any time. We honour our machines' warranty and service by using the barcode. This ensures your maximum convenience on both the maintenance and resell of your machinery.
Latest Model Quoted: Seeing that the tender above relates to our newest model, the climax, details and attachments are suitable thereto. Our sales representatives can be contacted relating to any enquirers of the period model cited. Based on lesser execution or lesser composition, you will be titled to pocket a 5% discount on older models, in which case we don't have the brand new model obtainable. The quotation above pertains to our newest model, and as such the highlights, specifications, accessories are applicable thereto. Kindly enquire from our sales representative as to the year model quoted. In the event that we do not have the newest model available, you will be entitled to receive up to 5% discount on the older model, dependent on lesser performance or lesser design.
